GPS/GNSS Antennas

Single and Dual band GPS/GNSS Timing Antennas

Filter and Amplify Global Positioning System Signals

GPS/GNSS timing antennas in Single and Dual Band options. GPS active antennas filter and amplify global positioning system signals received from local and global satellite constellations. They recover timing and positioning data for timing reference and phase synchronization.

These antennas are designed with integrated High Gain Low Noise Amplifiers that feature high out-of-band rejection. Increased position accuracy in densely populated urban canyons, flexible installation, and improved system security; are all advantages of this design. Standard connector options and fully ruggedized IP67 Rated units available.

Features

  • Multiple GNSS Systems Supported
  • High Gain
  • Low Noise Figure
  • Excellent Axial Ratio
  • IP67 Rated
  • External Grounding Lug

Applications

  • Global: GPS (L1 / L5), Galileo (E1 / E5), GLONASS (G1 /G3)
  • Local: BeiDou (B1 /B2), IRNSS (L5)
  • Timing and Positioning Phase Synchronization
  • High Accuracy Mission Critical Global Positioning
  • Military and Security



GPS/GNSS Timing Antenna Products:

GP-L1L5-40-N
GP-L1-32-T
GP-L1-32-T-MNT

Standard Performance Parabolic Reflector Antennas

Standard Performance non shrouded designs provide an economical point-to-point solution for applications that allow relaxed side lobe and front-to-back electrical operating characteristics. RadioWaves standard performance antennas are spun aluminum reflectors that feature cast aluminum mounts and are available with either plane (SP) or dual polarized (SPD) feed assemblies. Further these designs incorporate fine azimuth and elevation adjustments for ease of alignment. Standard models utilize optional ABS conical Radomes for reduced windloading and feed assembly protection

View All Products

High Performance Parabolic Reflector Antenna

High Performance parabolic antennas support applications where frequency congestion and coordination are demanded requiring more stringent radiation side lobe and front to back suppression characteristics. These are available in either plane (HP) or dual polarized (HPD) feed assemblies. These antennas are formed from aluminum which is spun to precise tolerances. They are fitted with planer Radomes to protect the feed. These designs incorporate fine azimuth and elevation adjustments for ease of alignment.

View All Products

Super High Performance Parabolic Reflector Antenna

Super High performance parabolic antennas support the most demanding of applications where performance is of paramount importance. These antennas minimize interference as they exhibit more stringent radiation side lobe and front-to-back suppression characteristics than HP models. They offer a lower profile and better wind performance than competitive brands. They are easily installed using RadioWaves superior mounting system included with the antenna. A cloth Radome is included. These are available in either plane (SHP) or dual polarized (SHPD) feed assembly form. Designs offer broadband performance for ease of SKU management and network planning/rollout. These designs incorporate fine azimuth and elevation adjustments for ease of alignment.
