GP-L1-32-T

L1 GPS/Timing Antenna, RHCP Polarized, 1.571 to 1.61 GHz

GP-L1-32-T, GP-L1-32-T

The GP-L1-32-T GPS antenna recovers timing and positioning data for timing reference and phase synchronization. It filters and amplifies global positioning system signals received from GNSS, Galileo, BeiDou, QZSS satellite constellations.

The GP-L1-32-T antenna is designed with an integrated 32 dB LNA and operates within the L1 1.571 to 1.61 GHz bands. It is fully ruggedized IP67 Rated. The LNA is DC fed through the TNC Female connector and is externally grounded.
