Parabolics

Standard and High-Performance Parabolic Point-to-Point (PTP) Antennas

Single or dual polarized standard and high-performance parabolic antennas

RadioWaves designs and manufactures Standard Performance (SP), High Performance (HP) and Super High Performance (SHP) series for terrestrial microwave point-to-point applications. These antennas support Telecoms, Enterprise and Industrial applications. They are available as single or dual polarized antennas and support standard frequency bands from 1.3 to 86 GHz. The products include 1 ft. (30 cm), 1.5 ft. (45 cm), 2 ft. (60 cm), 3 ft (90 cm), 4 ft. (120 cm), 6 ft. (180 cm) and 8ft (240 cm) diameter antennas.

Radio Waves leads the wireless industry with high-performance, low-profile, light-weight antennas. For greater efficiencies and customized packaging, the HP series offers direct integration of customers’ outdoor units (ODUs) to the antennas.

RadioWaves HP and SHP Series antennas are certified by CETECOM ICT Services GmbH to European Telecommunications Standard Institute (ETSI) standards. In addition, they comply with Federal Communications Commission (FCC) and Industry of Canada regulations, while meeting or exceeding EIA-195C and EIA-222E Standards.

The latest additions to RadioWaves portfolio of parabolic antennas include the HPPRO Professional Line and HPC Commercial Line.

RadioWaves HP PRO Line Parabolic Antennas offer Class 3 ETSI pattern performance and improved gain for demanding applications where only the best performance will do. In the PRO line,  RadioWaves has redesigned key components of our high performance parabolic antenna line to provide higher gain and reduced interference, enabling improved support for a broader range of network topologies while delivering better range and higher capacity. The PRO line carries Radiowaves industry leading 7 year warranty.

RadioWaves HPC Commercial Series antennas have been optimized by design for cost effective implementations around the globe, enabling RadioWaves to offer a value focused design while maintaining the excellent RF performance that networks require. The HPC Series antennas are value priced for economical deployments and come fully pre-assembled. Compliant to ETSI and FCC standards, with wind ratings of -125mph minimum operating and 155mph survival, the HPC Series is built to last. Waveguide and direct mount interfaces are available. The HPC Series includes a three-year warrranty.



Standard and High-Performance Parabolic Point-to-Point (PTP) Antennas Products:

PARABOLICS

Standard Performance Parabolic Reflector Antennas

Standard Performance non shrouded designs provide an economical point-to-point solution for applications that allow relaxed side lobe and front-to-back electrical operating characteristics. Radiowaves standard performance antennas are spun aluminum reflectors that feature cast aluminum mounts and are available with either plan (SP) or dual polarized (SPD) feed assemblies. Further these designs incorporate fine azimuth and elevation adjustments for ease of alignment. Standard models utilize optional ABS conical Radomes for reduced windloading and feed assembly protection

View All Products

High Performance Parabolic Reflector Antenna

High Performance parabolic antennas support applications where frequency congestion and coordination are demanded requiring more stringent radiation side lobe and front to back suppression characteristics. These are available in either plane (HP) or dual polarized (HPD) feed assemblies. These antennas are formed from aluminum which is spun to precise tolerances. They are fitted with planer Radomes to protect the feed. These designs incorporate fine azimuth and elevation adjustments for ease of alignment.

View All Products

Super High Performance Parabolic Reflector Antenna

Super High performance parabolic antennas support the most demanding of applications where performance is of paramount importance. These antennas minimize interference as they exhibit more stringent radiation side lobe and front-to-back suppression characteristics than HP models. They offer a lower profile and better wind performance than competitive brands. They are easily installed using Radiowaves superior mounting system included with the antenna. A cloth Radome is included. These are available in either plane (SHP) or dual polarized (SHPD) feed assembly form. Designs offer broadband performance for ease of SKU management and network planning/rollout. These designs incorporate fine azimuth and elevation adjustments for ease of alignment.

View All Products

High Performance Commercial Line Parabolic Antenna

HPC Commercial Series antennas have been optimized by design for cost effective implementations around the globe, enabling RadioWaves to offer a value focused design while maintaining the excellent RF performance that networks require. The HPC Series antennas are value priced for economical deployments and come fully pre-assembled. Compliant to ETSI and FCC standards, with wind ratings of -125mph minimum operating and 155mph survival, the HPC Series is built to last. Waveguide and direct mount interfaces are available. The HPC Series includes a three-year warrranty.

View All Products

Can’t Find What You’re Looking For? Contact Us to Discuss Custom Options.
